Loop Powered Oil Flow Meter: Two-Wire Savings for Simplified Network Routing
Quick Answer: A loop powered oil flow meter transmits a 4-20 mA signal and draws operating power through the same two wires. This eliminates a dedicated power cable, cuts material costs, and makes network routing in a plant much easier. Silver Automation Instruments supplies oval gear and turbine oil meters with loop powered outputs, HART 7, and certifications for ATEX Zone 1.
Why Loop Power Matters for Oil Flow Measurement
Oil flow measurement often happens at remote tank farms, blending skids, or offshore platforms. Running separate power and signal cables inflates the bill in cable trays, conduit, junction boxes, and man hours. A two wire 4-20 mA loop powered meter merges power and signal onto one shielded twisted pair. The control room sends 24 V DC, and the same loop returns the flow reading. We have seen this adopted widely in biodiesel plants in Malaysia and lubricant blending sites in the UAE.
In hazardous areas loop power keeps energy low by design. Pairing a loop powered flow meter with a single intrinsic safety barrier often satisfies ATEX Zone 1 or IECEx Zone 0 requirements without extra isolators. Many engineers prefer this because it shrinks the number of certified components in the loop and speeds up safety documentation.
Two Wire Savings for Cable Routing and Network Design
Most project managers underestimate wiring costs until they see the cable schedule. Adding one extra conduit to a pipe rack can cost more than the instrument itself. A loop powered oil flow meter brings signal and power over existing instrument cable infrastructure. No AC socket is needed near the pipe. At a refinery in Indonesia that Silver Instruments supported in 2023, switching 28 flow points from four wire magmeters to two wire oval gear meters saved roughly USD 18,000 in cable, gland, and labour costs.
Because the wiring is leaner, network routing becomes straightforward. You can run multiple 4-20 mA pairs inside a single multicore cable back to the marshalling cabinet. DCS, PLC, or a paperless recorder accepts the signal directly. No need for separate power distribution panels in the field. Loop powered meters also support HART communication over that same pair. You get secondary variables such as temperature, totalizer, and diagnostic flags with zero extra copper. A loop powered oil meter with a PT100 input can output compensated volume, which is helpful when oil density shifts with temperature.
Oil Flow Meter Types That Operate on Two Wire Loop Power
Not every flow technology can live on 4-20 mA loop power alone. Coriolis mass flow meters need drive coil energy, so the vast majority are four wire. Ultrasonic and thermal mass meters also usually demand separate power. Positive displacement and certain turbine designs are the practical choices for loop powered oil service.
Silver Instruments oval gear flow meters, such as the OGF series, use two precision rotors that rotate with the oil volume. The meter delivers actual volumetric flow largely independent of viscosity. A measurement of diesel at 8 cP and a measurement of heavy gear oil at 650 cP turn the rotors the same number of times for the same true volume. A low power pickup or Hall effect sensor generates pulses. The two wire converter conditions this into a 4-20 mA loop signal. Sizes run from DN4 up to DN80. Standard process temperature is 200 °C, and a high temperature version reaches 300 °C. Maximum pressure rating is 400 bar. With HART, the loop also transmits the PT100 oil temperature and the local flow total.
For thinner oils like kerosene, diesel, or light crude, a loop powered turbine flow meter is a lower cost alternative for pipe sizes DN15 to DN200. The rotor spins, a magnetic pickup creates a frequency signal, and a two wire converter delivers the 4-20 mA. These work well from roughly 0.5 m³/h upward when viscosity stays below 30 cP. At higher viscosities the flow profile changes and oval gear becomes more accurate.
Installation Details That Trip People Up
Most engineers skip this part until the startup day. A
In cold climates or with high viscosity oil, the metal meter body can act as a heat sink. Oil thickens and the rotor drag increases. If the meter sits outdoors in southern Australia, New Zealand, or Chile, add trace heating and insulation on the pipe and meter body. Keep the electronics housing below 60 °C ambient. Do not wrap the converter head.
A paint manufacturer in Vietnam contacted us last year about a loop powered oval gear meter for solvent based paints. Ground loops caused fluctuating readings. We suggested adding a loop isolator module and tying the meter body to one single earth point. The noise disappeared and the 4-20 mA signal locked stable.
When Four Wire Is the Better Call
If your oil stream contains entrained gas or you need direct mass flow in kg/h without density math, a Coriolis meter is the correct tool and it needs four wire power. For custody transfer of crude oil, turbine meters with pulse outputs and external powered flow computers remain the common choice. If you measure additive injection below 0.1 L/h, the signal resolution from a loop powered oval gear may be too coarse, and a micro Coriolis with separate power is preferred. For the majority of internal process control, blending, and batching tasks, a loop powered positive displacement meter works well.
Next Step and Quote Request
Send us your oil type, operating viscosity (cP), flow range (for example 10 to 300 L/h), pipe size (DN), process temperature (°C), and hazardous area classification. Our application team responds within one business day with a model recommendation, a dimensional drawing, and a price in USD or AUD. We ship to Southeast Asia, Oceania, Latin America, Africa, and the Middle East from stock held in Singapore and Australia.
Specify if you need ATEX, IECEx, or PESO certification. Loop powered oil flow meters from Silver Instruments can include integral digital display, HART 7, and PT100 temperature input. Email your enquiry or use the form on flow-meter.com.au.
FAQ
Q: Can a loop powered flow meter handle heavy fuel oil with viscosity above 500 cP?
A: Yes. Silver Instruments oval gear meters measure reliably up to 100,000 cP with minimal accuracy shift. The loop powered signal conditioner functions independent of viscosity as long as the rotors turn. Specify high viscosity bearings if your oil stays above 1000 cP.
Q: What is the maximum wiring distance for a two wire loop powered meter?
A: With a 24 V DC supply and a 250 ohm load, you can typically reach 1000 meters using 1.5 mm² cable. We can provide a loop calculation sheet if you share cable type and barrier resistance. Beyond 1000 meters we advise a four wire system or a local power supply.
Q: Do you offer loop powered oil flow meters with HART for remote diagnostics?
A: Yes. All our OGF series and turbine meters can include HART 7 communication. You read flow rate, total, temperature, and diagnostic flags over the same two wires.
Q: How do I decide between an oval gear meter and a turbine meter for diesel?
A: For diesel between 2 and 50 cP, a turbine meter works well and has a lower cost in DN50 and larger sizes. If you need high accuracy across a wide viscosity span, or your diesel contains biodiesel blends with variable viscosity, choose an oval gear meter. Silver Instruments supplies both types with loop powered output.
Q: Can I use a loop powered oil flow meter in Zone 1 with intrinsic safety?
A: Yes. The meter must carry Ex ia IIC certification and have entity parameters listed in the control drawing. Silver Instruments provides ATEX and IECEx approved meters for use with compliant IS barriers. State your gas group and zone when you request a quote.
